FEATURES

• Long life metal halide lamp
• 5600°K color temperature
• Automatic self-cancelling color boomerang (snapaction, optional)
• Automatic single leverzoom lens system
• Balanced for perfect weight distribution at any operating angle
• Easily carried by two persons
• Horizontal trim shutters
• Heavy duty nichrome steel iris
• Template slot pattern (gobo) projection furnished as standard
• Folding three-legged base with locking casters and leveling jacks
• Draws 15 amps at 120 VAC 60 Hz. (240v.,50Hz. optional)
• Adjustable brakes for pan and tilt
• Dowser
• Quiet operation

Dimensions

• Head length - 48" (121.9cm)
• Head height - 191/" (49.5cm)
• Overall height with base 571/2" (146.5cm)
• Height of pivot • 481/" (123.2cm)
• Additional upward height adjustment of 13° (33.2cml
• Width of base- 34" (86.4cm)
• Maximum width of head - 17" (43.2cm)
• Head weight - 86 Ibs. (39.0 Kg)
• Base weight - 41 lbs. (18.6 Kg)
• Power supply weight - 52 lbs. (23.59 Kg)

Photometrics
